Engine | 48-volt DC |
Horsepower | 3.7 hp (2.7 kW) rated, Peak 20 hp (14.9 kW) |
Battery | (6) – 8-volt flood lead acid |
Charger | DeltaQ QuiQ (1 kW high frequency) |
Speed | 8-27 km/h |
Steering | Self-adjusting rack & pinion |
Front Suspension | Independent Leaf Spring w/dual Hydraulic Shocks |
Turning Radius | 413.4 cm |
Brakes | 4 Wheel Mechanical Drum. |
Park Brake | Foot operated, Multi-lock |
LxWxH | 349.3 x 126.5 x 119.6 cm |
Bed (LxWxH) | 166.3 x 120.6 x 26.6 cm |
Wheelbase | 251.7 cm |
Ground Clearance | 14.2 cm |
Tyres | 20 x 10 – 10, 6-ply |
Curb Weight | 669 kg |
Bed Load Capacity | 453.6 kg |
Towing Capacity | 680.3 kg |
